How Do I Choose the Right LED Strip for Under-Cabinet Lighting?

Under-cabinet lighting is a stylish and functional way to brighten up your kitchen, office, or workspace. LED strips have become a popular choice for under-cabinet lighting due to their energy efficiency, slim profile, and versatility. But with so many options available, how do you choose the right LED strip for your project? This guide will walk you through key considerations to help you select the perfect LED strip for under-cabinet lighting in your residential or commercial spaces.

Why Choose LED Strips for Under-Cabinet Lighting?

LED strips are ideal for under-cabinet lighting because they provide uniform, energy-efficient illumination in a thin, flexible form. They’re easy to install and can be cut to fit any length, making them highly customizable for different cabinet sizes.

Additionally, LED strips are low-voltage and come in various color temperatures, allowing you to create the right atmosphere, whether it’s for task lighting in the kitchen or ambient lighting in an office.

Key Considerations When Choosing LED Strips for Under-Cabinet Lighting

1. Brightness: How Much Light Do You Need?

The brightness of your LED strip will depend on how you intend to use it. If you need task lighting for cooking or reading, you’ll want an LED strip that offers a high lumen output. For a more ambient or decorative effect, a softer, less intense strip may be ideal.

Lumen Output: Choose an LED strip with at least 300-500 lumens per meter for general under-cabinet lighting. Higher lumen output is recommended for task-oriented spaces like kitchens.

2. Color Temperature: Choose the Right Tone

The color temperature of your LED strip affects the overall mood and functionality of the space. Under-cabinet lighting is available in various color temperatures, from warm white to cool white.

l Warm White (2700K-3000K): Best for creating a cozy, welcoming atmosphere in living spaces or kitchens with wooden cabinetry.

l Neutral White (3500K-4000K): Provides a balance between warm and cool light, making it suitable for general under-cabinet lighting in offices and kitchens.

l Cool White (5000K-6000K): Ideal for bright task lighting, such as for reading, cooking, or other detailed activities.

Tip: If you want flexibility, consider using CCT tunable LED strips, which allow you to adjust the color temperature depending on the time of day or the task at hand.

3. Voltage: Choose Between 12V and 24V

LED strips come in two main voltage options: 12V and 24V. The choice between the two depends on the length of the strip and the power requirements of the installation.

l 12V LED Strips: Suitable for shorter lengths and easy to install. However, you may experience more voltage drop over longer runs.

l 24V LED Strips: Ideal for longer installations, as they offer better voltage stability and less voltage drop. For large cabinets or installations that require more power, 24V is usually the better choice.

Tip: For long runs (over 5 meters), opt for 24V strips to ensure consistent brightness across the entire length.

4. Waterproof or Non-Waterproof

While most under-cabinet LED strips are non-waterproof, some areas, such as kitchens or wet bars, may require IP65-rated waterproof LED strips.

l IP20 (Non-Waterproof): Suitable for dry areas or environments where water exposure is not a concern.

l IP65 (Waterproof): Ideal for areas where splashes or humidity may occur, such as under-sink cabinets or areas near a stovetop.

Tip: Choose waterproof LED strips if you're installing under-cabinet lighting near water sources.

5. Adhesive or Mounting Options

LED strips come with either self-adhesive backing or mounting clips for installation. For under-cabinet lighting, the adhesive backing is typically sufficient for most applications, making it an easy and mess-free installation.

l Adhesive Backing: Quick and easy to install on smooth surfaces.

l Mounting Clips: Ideal for more permanent installations, especially in commercial or high-traffic areas.

Tip: If you need to reposition or change the strip in the future, go with adhesive-backed strips for ease of installation and removal.

6. Power Supply and Dimming Capability

For a smooth under-cabinet lighting experience, choose an LED strip that matches your power supply requirements. Also, consider whether you want to incorporate dimming features for adjustable light levels.

l Ensure your power supply can handle the total wattage of the LED strip, especially if you have multiple strips.

l Dimmable LED strips provide flexibility, allowing you to adjust the brightness based on your needs.

How to Install LED Strips Under Cabinets

Once you’ve chosen the perfect LED strip for your needs, follow these simple steps for installation:

1.  Measure the Length: Measure the length of your cabinets to ensure the LED strip fits perfectly.

2.  Clean the Surface: Clean the underside of the cabinet to ensure good adhesion for the self-adhesive backing.

3.  Install the Power Supply: Mount the power supply in an accessible location, ensuring it is compatible with your LED strip's voltage.

4.  Apply the LED Strip: Stick the LED strip to the underside of the cabinet, ensuring it runs in a straight line for uniform lighting.

5.  Connect the Controller: If using a dimmable LED or CCT tunable strip, connect the controller to adjust settings via remote or app.

Conclusion

Choosing the right LED strip for under-cabinet lighting can transform your space by providing efficient, bright, and customizable lighting. Consider key factors like brightness, color temperature, voltage, waterproofing, and installation ease to ensure you select the best product for your project.
